An additional system developed by Eurorad allows dual optical detection (fluorescence-nuclear) for ganglion localization.
This dual dye and radioisotope detection method within one device is a world-wide exclusivity.
Optional add-on module.
Allows dual Gamma and Fluorescence detection.
Selection of detection modality through a foot switch.
Simple and identical use to the Gamma procedure.
Ready-to-use at normal light conditions.
No specific installation required.
Improved discrimination and sensitivity.
Europe: CE 0459 (G-Med: classe 2a)
USA FDA registered: 9032627
Module height: 55mm
Weight: 1 Kg
Width / Depth: 233 mm / 270 mm
Suitable for of Indocyanine Green (ICG) detection
Watch the video of a gamma/fluo detection in the operating room.
Opto-nuclear probes are designed to detect both isotopic markers and fluorescent markers (ICG).
The SOE3214-AF probe is for endoscopic procedures, and the use of trocarts.
Reference | Type of probes | Cut Ø / Length (mm) | Form / Playback |
SOE 3214 | Opto-nuclear detection (double reading) | 12/194 | Straight/Axial |
SOE 3214-AF | Opto-nuclear frontal laparoscopic detection (double reading) | 122/426 | Straight/Axial |
Dual detection probes: CdTe (Cadmium Telluride) and Fluorescence
Energy: 20 – 300 keV (Optimum efficiency: 20 – 170 keV)
Isotopes: 125I, 99mTc, 111In.
Sensitivity of fluorescence detection: <1nmol of ICG
